GRChombo and GRTeclyn

Panel discussion introduction

Miren Radia

University of Cambridge

Wednesday 23 July 2025

Predecessor/current code: GRChombo

  • Built on the Chombo libraries for “fully-adaptive” block-structured AMR
  • Written in C++14
  • Explicit vectorization through C++ templates to achieve good performance
  • Hybrid MPI + OpenMP parallelization
  • Project started in ~2012 with code becoming open source in 2018.
  • Intended for more exotic problems than some other NR codes:
    • Cosmology: Inflation, cosmic strings, etc.
    • Boson stars/oscillatons/axion stars
    • Modified gravity
    • Higher-dimensional BHs
    • Much more

Successor/future code: GRTeclyn

  • GRTeclyn is an in-development port of GRChombo to AMReX.
  • “Teclyn” is Welsh for “tool”.
  • Features:
    • Built on the AMReX framework for block-structured AMR with good GPU support.
    • Higher-order spatial interpolation between coarser and finer levels than GRChombo.
    • Black-hole binary evolution
    • Familiar structure for existing GRChombo users
    • Tested and runs well on Nvidia, AMD and Intel GPUs

A bar chart showing the mean walltime taken to evolve a single timestep on various different GPUs and a CPU. The results are as follows: Intel Xeon Platinum 8480 CPU (480s), Nvidia GH200 GPU (56s), AMD MI300X GPU (76s), AMD MI210 GPU (358s), Nvidia A100 GPU (105s) and Intel PVC 1550 (176s).

Methods

  • Cell-centred finite-difference discretization
  • Block-structured AMR
    • Can emulate “moving boxes” for compact object binaries
    • Generally something more adaptive for more exotic spacetimes
    • Can fix some of the coarser grids to avoid regridding noise near GW extraction spheres
    • Arbitrary refinement criterion
  • Method of lines
    • Fourth order Runge-Kutta time integration
    • Fourth or sixth-order spatial discretization
  • Kreiss-Oliger dissipation
  • Boundary conditions:
    • Fourth order interpolation at finer level boundaries from coarser levels
    • Outgoing radiation (Sommerfeld)
    • Symmetric/reflective
    • Extrapolating
  • CCZ4 evolution system
  • Moving puncture gauge conditions

Coding paradigms

  • Simple structure in modern C++ that is easy to adapt to new problems.
    • We inherit this from Chombo/AMReX (both very similar).
  • No complicated code-generation procedures
    • Easier to debug and/or modify
  • Low number of dependencies
    • Easier to set up/simplifies portability
  • Performance optimization e.g.:
    • GRChombo: Explicit vector intrinsics instead of relying on compiler auto-vectorization
    • GRTeclyn: No GPU managed memory to keep data GPU-resident and avoid unnecessary transfers

Challenges and solutions

Shorter term

Challenges

  • Transitioning GRChombo users to GRTeclyn
  • Training research users how to modify/develop/run in a GPU-performant way
  • Improving scientific productivity (time and computational resources)

Solutions

  • Training/group hackathons
  • Better documentation
  • Collaborate with other codes on developing shared tools

Longer term

  • Future GPU performance is only really improving in lower precision floating point datatypes (e.g. 32 bit, 16 bit, 8 bit and even lower).
    • Like everyone else we currently use FP64 (double precision) everywhere.
    • We will need more accuracy for future GW detectors, not less!

Any questions?

Why AMReX?

  • Mature and performant cross-vendor (Nvidia/AMD/Intel) GPU support
  • Similar block-structured AMR capabilities to Chombo1
  • AMReX previously received significant support as part of the US Exascale Computing Program (ECP).
    • There are many AMReX applications across diverse research areas.
    • Large user community (Slack workspace/GitHub discussions)
  • AMReX is now an established project in the High Performance Software Foundation.
  • Helpful and very active development team:
    • In particular, Weiqun Zhang has been instrumental in helping us to get started.
